mimic panel

The Control of Dynamic Mimic Panel Implemented by Process Control Configuration Software

利用工控组态软件实现动态模拟屏的控制

The paper designs the data table structure of derivative database and brings forward middle-route calculation algorithm for light band state of command mimic panel.

对软件系统设计了关系量数据库的数据表结构，提出调度模拟屏光带带电状态的中间量路由计算算法。

The Design of Light Band Topology Calculation Software for Telecontrol Mimic Panel in Electrified Railway

电气化铁道远动调度模拟屏系统光带拓扑逻辑计算软件设计

With the example of a 2000t/ d clinker pre decomposed kiln cement plant the structure design of dynamic mimic panel control system and the principle of the circuit of dynamic controller are analyzed in detail.

以日产2000t熟料预分解窑水泥厂为例，详细分析了动态模拟屏控制系统的结构设计及动态控制器线路的原理。

Precisely because its purpose is to provide a general sense of system activity, the mimic panel is not designed to display specific events in a way that commands the attention of an individual operator.

因为其目的是为系统活动提供一般含义，所以模拟盘并不是为以掌控单个操作员的注意力的方式显示具体事件而设计的。

The distributed and platform-independent software system of telecontrol mimic panel for new type of electrified railway, developed in JAVA language, realizes prompt indication of command data in mimic panel via accessing data from real-time database server.

利用java语言开发的分布式、跨平台的新型电气化铁道远动系统调度模拟屏软件系统，通过调用实时数据库服务器中的数据，实现调度数据的实时模拟屏显示。

From the mimic panel and color display device, the dispatchers can directly visualize the real time information of main grid.

从模拟屏和彩色显示器上，调度员可直接看到主干网的实时信息。

Modulating the display of information according to individual operators can help to ratonalize the display resources of the mimic panel.

根据个人操作员调整信息显示有助于使模拟盘的显示资源合理化。
